User manual
Table Of Contents
- 1. Introduction
- 2. Technical data
- 3. For your safety
- 4. Transport, storage and disposal
- 5. Commissioning
- 6. Functional description
- 6.1 Operation
- 6.2 The Work mode
- 6.3 Parameter mode
- 6.4 Configuration mode
- 6.5 Factory settings (“default”)
- 6.6 Contrast
- 6.7 Replacing the soldering tip
- 6.8 Changing the Heating Element
- 6.9 Sensitive components
- 7. Error diagnosis and remedy
- 8. Maintenance
- 9. Replacement parts
- 10. Warranty
i-CON 1 / 42
3BA00180 • 28.04.2008 • Rev. 1
Operating instructions
Code Test in display Cause Remedy
2
[CALIBRATION FATAL ER-
ROR !]
Station no longer calibrated Have factory calibration car-
ried out
4
[RT-compensation] Measurement reading of KTY
not ok
Have soldering tool and sol-
dering station checked
7
[HE MISSING ? SENSOR ?] Heating element is not in-
stalled correctly
Thermocouple error
Install heating element cor-
rectly
Have soldering tool checked
8
[HEAT ELEMENT?] Heater defect Check heating element /
Check soldering station
9
[DATA LOST!] Parameter/Congurationdata
destroyed
Reset soldering station to fac-
torysettinginthecongura-
tion mode
71
[iTOOL AND HE DEFECTIVE/
EXCHANGE]
Both the electronics and the
heating element of the i-Tool
are defective.
Replace the i-Tool
98
[MAINS FREQUENCY ER-
ROR]
Mains frequency outside of
frequency range (± 10%)
-
99
[iCON OVERLOAD PRO-
TECTION]
Soldering station overloaded Allow the soldering station to
cool down
