RBS 210 6 and RBS 2206Radio Configurations
Table 24 CDU-G without Hyb rid Combiner
Max. No. of TRXs No. of Antennas
Cell: Cell:
No.
of
Cell s
1 2 3 1 2 3
See:
2 4
(1)
2 4 2 Cell 1: Figure 13 on p age 23
Cell 2: Figure 12 on page 21
2 —
(2)
2 2 2 Figure 12 on page 21
3
(3)
2 2 2 2 2 2 Figure 12 on page 21
2 2 2 2 2 2 Figure 12 on page 21
(1) The sector with four TRXs should always be placed t o the left.
(2) The middle position in the cabinet must be left empty.
(3) TMA can be selected per frequency band. If sector 2 has TMA, then the other sector with the
same frequency must also have TMA. If secto r 2 does not have TMA, then the other sector with
the same frequency band cannot have T MA.
The following frequenc y band combinations are possible: P-G SM 900/GSM
1800, E-GSM 900/GSM 1800, GSM 800/GSM 1800, and GSM 800/GSM 1900.
CDU-G Dual Band Conf ig uration with a Mix Hybrid Combiner and
Unc ombined
Table 25 CDU-G Dual Band Configuration with a Mix Hybrid Combiner and Uncombined
Max. No. of TRXs No. of Antennas
Cell: Cell:
No.
of
Cell s
1 2 3 1 2 3
See:
2 8c
(1)
2u
(2)
4 2 Cell 1: Figure 20 on page 38
Cell 2: Figure 12 on page 21
2u 8c 2 4 Cell 1: Figure 12 on page 21
Cell 2: Figure 20 on page 38
4c 2u 2 2 Cell 1: Figure 16 on page 30
Cell 2: Figure 12 on page 21
2u 4c 2 2 Cell 1: Figure 12 on page 21
Cell 2: Figure 16 on page 30
3
(3)
2u 2u 4c 2 2 2 Cell 1 and 2: Figure 12 on page 21
Cell 3: Figure 16 on page 30
4c 2u 2u 2 2 2 Cell 1: Figure 16 on page 30
Cell 2 and 3: Figure 12 on page 21
