Product Description Part 2

RBS 210 6 and RBS 2206 Radio Configurations
Table 21 CDU-G con figurations for GSM 80 0, P-GSM 900, E-GSM 900, GSM 1800 or
GSM 19 00
Max No. of TRXs No. of Antennas
Cell: Cell:
No. of
Cells
1 2 3 1 2 3
See:
2 8c
(1)
2u
(2)
4 2 Cell 1: Figure 19 on page 36
Cell 2: Figure 12 on page 21
(1)
8H
(3)
2u 2 2 Cell 1:Figure 19 on page 36
Cell 2: Figure 12 on page 21
2u 8H 2 2 Cell 1: Figure 12 o n page 21
Cell 2: Figure 19 on page 36
8H 4c 2 2 Cell 1: Figure 19 on page 36
Cell 2: Figure 16 on page 30
4c 8H 2 2 Cell 1: Figure 16 on page 30
Cell 2: Figure 19 on page 36
2u 8c 2 4 Cell 1: Figure 12 on page 21
Cell 2: Figure 19 on page 36
2u 4c 2 2 Cell 1: Figure 12 on page 21
Cell 2: Figure 16 on page 30
4c 2u 2 2 Cell 1: Figure 16 on page 30
Cell 2: Figure 12 on page 21
4u 4c 4 2 Cell 1: Figure 13 on page 23
Cell 2: Figure 16 on page 30
1u+2c 1u+2c 2 2 Cell 1: Figure 15 on page 28
Cell 2: Figure 13 on page 23
3 2u 2u 4c 2 2 4 Cell 1 and 2: Figure 12 on page 21
Cell 3: Figure 16 on page 30
2u 4c 2u 2 4 2 Cell 1 and 3: Figure 12 on page 21
Cell 2: Figure 16 on page 30
2u 4c 4c 2 4 4 Cell 1: Figure 12 on page 21
Cell 2 and 3: Figure 16 on page 30
4c 2u 2u 4 2 2 Cell 1: Figu re 16 on page 3 0
Cell 2 and 3: Figure 12 on page 21
4c 2u 4c 4 2 4 Cell and 3: Figure 16 on page 30
Cell 2: Figure 12 on page 21
4c 4c 2 u 4 4 2 Cell 1 and 2: Figure 16 on page 30
Cell 3: Figure 12 on page 21
45 (62)
EN/LZT 720 0318 Uen R5A
