Product Description Part 2

RBS 210 6 and RBS 2206 Radio Configurations
In the figure above, Ant S1 and Ant S5 represent the antenna sharing signal
which goes to the next cabinet. For connector numbers, see Table 16 on
page 41.
Characteristics
Number of CDUs 3
Frequen cy band GSM 800
P-GSM 900
E-GSM 900
Max. number of TRXs 12
Number of feeder s 3
Number of antennas 3
Antenna configuration 2 x TX/RX + TX
TMA configuration (optional) ddTMA + ddTMA
Note: The ASU is optional equipment.
Table 16 Configurations with 1 x 12 CDU-G with HCU
Antenna TM A
Antenna Sharing
Con nector
CDU CXU/dTRU
No.
(TMA
Config. Only)
(Co
-siting Only)
No.
/Connector
No.
/Connector
TX/RXA 1 1 1/TX/RX 1 1..6/RX1
TX/RXB 5 5 3/TX/RX 1 1..6/RX2
6 Site Cell Configurati ons (SCC)
This section shows SCCs in on e RBS. More RBSs can be combined to form
larger configurations at a site. Possible expansions, where different RBSs are
connected using TG-synchronisation, are described in Section 7 on page 50.
The following SCCs are supported by the RB S:
• Specified basic radio configurations
• The R BS with any number of dTR Us within the specified range inserted in
the spec ified position order
