Product Description Part 2

RBS 210 6 and RBS 2206 Radio Configurations
Characteristics
Number of feeder s 2
Number of antennas 2
Antenna configuration TX/RX + TX/RX
TMA configuration (optional) ddTMA + ddTMA
Note: The ASU is optional equipment.
Table 14 1 x 8 Configurations with CDU-G with HCU
Cell
Antenna TMA Antenn a
Sharing
Connector
CDU CX U/dTRU
No. (TMA Config.
Only)
(Co-siting
Only)
No./Connec-
tor
No./Connec-
tor
1 TX/RXA 1 1 1/TX/RX 1 1..4/RX1
TX/RXB 3 3 2/TX/RX1 1..4/RX2
Alt.1 TX/RXA 3 3 2/TX/RX1 3..4/RX2,
5..6/RX1
TX/RXB 5 5 3/TX/RX1 3..4/RX1,
5..6/RX2
