Product Description Part 2

RBS 210 6 and RBS 2206 Radio Configurations
In the figure above, Ant S1, Ant S2 and so on re present the a ntenna sharing
signal which goes to the next cabinet. Fo r connector numbers, see Table 12
on page 33 .
Characteristics
Number of CDUs 2
(1)
Frequen cy band GSM 800
P-GSM 900
E-GSM 900
GSM 1800
GSM 1900
Max. number of TRXs 6
Number of feeder s 3
Number of antennas 3
Antenna configuration TX/RX + TX/RX + TX
TMA configuration (optional) ddTMA + ddTMA
Note: The ASU is optional equipment.
Table 12 2 x 6 Configurations with CDU-G
Cell
Antenna TMA Antenna
Sha ring
Con nector
CDU CX U/dTRU
No. (TMA Config .
Only)
(Co- siting
Only)
No./Connec-
tor
No./Connec-
tor
1 TX/RXA 1 1 1/TX/RX1 1/RX1, 2/RX1,
3/RX1
TX/RXB 2 2 1/TX/RX2 1/RX2, 2/RX2,
3/RX2
2 TX/RXA 5 5 3/TX/RX1 4/RX1, 5/RX2,
6/RX2
TX/RXB 6 6 3/TX/RX2 4/RX2, 5/RX1,
6/RX1
