Product Description Part 2

RBS 210 6 and RBS 2206 Radio Configurations
Note: The ASU is optional equipment.
Table 11 Configurations with CDU-G and 4 Combined TRXs per Cell
Cell
Antenna TMA Antenna
Sharing
Connector
CDU CXU/dTRU
No. (TMA
Config.
Only)
(Co-siting
Only)
No./Connector No./Connector
1 TX/RXA 1 1 1/TX/RX 1 1/RX1 , 2/RX1
TX/RXB 2 2 1/TX/RX 2 1/RX2 , 2/RX2
2 TX/RXA 3 3 2/TX/RX 1 3/RX2 , 4/RX2
TX/RXB 4 4 2/TX/RX 2 3/RX1 , 4/RX1
3 TX/RXA 5 5 3/TX/RX 1 5/RX2 , 6/RX2
TX/RXB 6 6 3/TX/RX 2 5/RX1 , 6/RX1
Configuration 2x6 CDU-G with Hybrid Combiner
