Product Description Part 2

RBS 210 6 and RBS 2206Radio Configurations
Con figuration 1x4 CDU-G with Hybrid Combiner
P007387C
TX/
RXA
TX/
RXB
DPX LNA DPX
TMA
(optional)
1
2
1
2
TMA
(optional)
Ant S1(3,5)
Ant S2(4,6)
TX1+TX2
RX1
RX2
dTRU
TX1
RX1
CDU-G
DPX
CXU
LNA
DPX
RX2
LNA
TX1+
TX2
RX1
RX2
dTRU
TX2
ASU
DPX LNA DPX
1 = Antenna Reference Point without TMA
2 = Antenna Reference Point with TMA
X
X
X
X
Figure 16 1x4 C DU-G Combined
In the figure above, Ant S1 and Ant S2 represent the antenna sharing signal
which goes to the n ext cabinet. For co nnector numbers, see Table 11 on
page 31.
Cha racte
ristics
Number of CDUs 1
Frequency band GSM 800
P-GSM 900
E-GSM 900
GSM 1800
GSM 1900
Max . number of TR Xs 4
Number of feeders 2
Number of ante nnas 2
Antenna configuration TX/RX + TX/RX
TMA configurat ion (optional) ddTMA + ddTMA
30 (62)
E
N/LZT 720 0318 Uen R5A
