Product Description Part 2

RBS 210 6 and RBS 2206 Radio Configurations
Characteristics
GSM 1800
Max. number of TRXs 4 per cabinet
Number of feeder s 2 + co-sitin g cables
Number of antennas 2
Antenna configuration TX/RX + TX/RX
TMA configuration (optional) ddTMA + ddTMA
Table 4 1 x 8 CDU-F (mid-sector)
Cell
Antenna TMA No.
(TMA
Con fig.
Only)
CDU
No./Con-
nector
CDU/dTRU
No./Con-
nector
2
Cabinet 1
TX/RXA 5 3/ TX/RX 5/RX2 ,
6/RX2
RXB
(1)
3/RX 5/RX1 ,
6/RX1
2
Cabinet 2
TX/RXB 1 1/ TX/RX 1/RX1 ,
2/RX1
RXA
(1)
1/RX 1/RX2 ,
2/RX2
(1) Via co-siting cable
Configuration 1x12 CDU-F
17 (62)
