Product Description Part 2

RBS 2207

• -48 to -6 0 V DC

• 120 - 250 V AC, 50 to 60 Hz , +24 V DC, with optional battery back-up

• +24 V DC (without PSUs)

1.3 Optional Equipment

The equipment listed below is available, but is not necessary for basic

functionality.

• Battery back-up (in a separate cabinet)

• Bias injectors

• dual duplex Tower Mounted Amplifier (ddTMA)

• External synchron ization bus (ESB)

• Distribution Frame (DF) with OVP

• TMA-CM

• Transmission Adapter (TA)

• GPS receiver

2 Dimensions

The following s ection describes the measurements of the RBS 2207.

Table 1 Weight

Unit Weight

RBS cabinet (fully equip ped including

base frame)

180 kg (397 lbs .)

Base f ra me 8 kg (18 lbs.)

Table 2 Color

Color Reference No.

Grey NCS 1002-R

3 Spa ce Requirements

The follo wing sections indicate the required space and recommende d flo or

layo ut .
