Product Description Part 2

RBS 210 6 and RBS 2206 Radio Configurations
Characteristics
Number of CDUs 2
(1)
Frequen cy band E-GSM
GSM 1800
Max. number of TRXs 6
Number of feeder s 2
Number of antennas 2
Antenna configuration TX/RX + RX
TMA configuration (optional) ddTMA + ddTMA or
ddTMA + rTMA
Table 2 2 x 6 Configurations with CDU-F
Cell
Antenna TMA
CDU CXU/dTRU
No. (TMA
Config. Only)
No./Connector No./Connection
1 TX/RXA 1 1/TX/RX 1/RX1, 2/RX1,
3/RX1
RXB 2 1/RX 1/RX2, 2/RX2,
3/RX2
2 TX/RXA 5 3/TX/RX 4/RX1, 5/RX2,
6/RX2
RXB 6 3/RX 4/RX2, 5/RX1,
6/RX1
