Product Description Part 2

RBS 210 6 and RBS 2206 Radio Configurations
Table 1 3 x 4 Configurations with CDU-F
Cell
Antenna TMA
CDU CXU/dTRU
No. (TMA
Config.
Only)
No./Connec-
tor
No./Connector
1 TX/RXA 1 1/TX/RX 1/RX1, 2/RX1
RXB 2 1/RX 1/RX2, 2/RX2
2 TX/RXA 3 2/TX/RX 3/RX2, 4/RX2
RXB 4 2/RX 3/RX1, 4/RX1
3 TX/RXA 5 3/TX/RX 5/RX2, 6/RX2
RXB 6 3/RX 5/RX1, 6/RX1
Configuration 2x6 CDU-F
