Table 42 PCM Parameter Settings for Transmission Interface T1,

Transmission Characteristics Unknown

PCM Parameter Settings

‘‘Long h., 0 dB’’, if usedLBO B

‘‘Short h., 0 – 133 feet’’, if unused

‘‘Long h., 0 dB’’, if usedLBO C

‘‘Short h., 0 – 133 feet’’, if unused

‘‘Long h., 0 dB’’, if usedLBO D

‘‘Short h., 0 – 133 feet’’, if unused

FDL Use See Site Installation Documentation.

7.6.14 Defining TEI

This section describes how to define the TEI value for the IXU.

1. On the Configuration menu, click Define and TEI to open the Define TEI

dialog box.

2. Click Run to open the Define TEI for IXU 0 window.

3. Enter the TEI value fou

nd in the Site Installation Documentation. Click OK.

7.6.15 Defining TNOM

This section describes how to define the Transport Network Operation and

Maintenance (TNOM) parameters if supported by the network.

1. On the Configuration menu, click Define and TNOM to open the Define

TNOM window.

2. Set TNOM Use to ‘‘On’’.

3. In the TNOM Timeslot box, enter a valid time slot value:

– 1 — 24 (default value 24), T1

– 1 — 31 (default value 31), E1

4. In the TNOM Node ID box, enter the correct values. Valid TNOM Node ID

values are 1 – 65534 (default value is 1). Click OK when finished.

7.6.16 Installing IDB

This section describes how to install the IDB in the RBS, by connecting the

OMT to the RBS and loading the IDB from the PC to the RBS.
