This message will be displayed in the BSC/OMT if the alarm is issued.
8. Click Apply after defining the alarm.
9. Repeat steps 2 to 8 to define remaining alarms.
10. Click OK when all alarms are defined.
Defining External Alarms for EBB and PBC
The alarms for EBB and PBC should be defined according to the tables below.
ddTMA
Table 26 External Alarm Definitions for ddTMA
Alarm
Inlet
Inlet
Usage
Type Id
Sever-
ity
Comment
0/3 External
Alarm
Breaking
(1)
Level 2 TMA equipment fault
0/6 External
Alarm
Breaking
(1)
Level 2 Battery backup is about
to end
0/7 External
Alarm
Breaking
(1)
Level 2 Check battery
(1) Preferably, ID should be set to the same number as the corresponding alarm inlet.
EBB-01
Table 27 External Alarm Definitions for EBB-01
Alarm
Inlet
Inlet
Usage
Type Id
Sever-
ity
Comment
0/5 External
Alarm
Breaking
(1)
Level 2 Battery backup fault
0/6 External
Alarm
Breaking
(1)
Level 2 Battery backup is about
to end
0/7 External
Alarm
Breaking
(1)
Level 2 Check battery
(1) Preferably, ID should be set to the same number as the corresponding alarm inlet.
