Specifications
888-SV-22FN-00 rev C
2
8
a Make sure riser is locked (lift brake down), then remove the two
capped screws anchoring the riser to the tower.
b Save the screws and caps in the provided
bag to be used if the riser needs to be
anchored to the tower at a later time.
2
Remove anchor screws connecting riser to tower.
riser
tower
a
b
WARNING: The riser can move up on its own
very quickly when a counter-balancing force is
removed! Therefore, always lock the riser down with
the lift brake when adding or removing equipment
and when removing or inserting the anchor screws
which secure the riser to the tower during ship-
ping. Failure to lock the riser at such times can
result in serious personal injury and possible
damage to cart and/or equipment.
a Lift up work surface and place notebook into enclosure.
b Attach adhesive velcro to bumpers and adhere to enclosure to keep notebook in place.
3
Attach notebook
a
b
Mounting Equipment
4
Personalize autolock drawer code.
a Unlock drawer with master key (identical
duplicate keys are provided). Pull drawer open
to access battery box; remove box cover; insert
the four provided AA batteries. Replace cover
and close drawer.
b Remove the Master Code sticker located
near the number pad and place it in the box at
right for safe keeping and future reference.
c Program Personal Code:
1 Enter Master Code
2 Press 3 and 5 at the same time
3 Enter a new personal code -
any series of five numbers
The drawer is now programmed to
unlock when either the personal code
or the master code is entered.
The drawer remains unlocked for 2 minutes
and the number 5 remains lighted. At the
end of two minutes, the drawer auto-
matically locks. You can manually lock the
drawer at any time by pressing 1 and 2 on
the number pad simultaneously.
a
Master Code
Four AA
1 2 3 4 5
b
c
1
Prepare for cart set-up.
2
1
a Gather tools for cart
set-up.
b To prevent the riser
from moving during
set-up, lock riser by
pushing the lift brake
down.
a
b
*
Store this guide along with the master keys in a secure
place to prevent unauthorized access to autolock drawer.
• 9/16"
• 3/8" (10mm)
