Using the Diagnostic Tool
ERASING DIAGNOSTIC TROUBLE CODES (DTCs)
OBD2 51
The first time the Vehicle ID function is used, it may take
several minutes
to retrieve the information from the vehicle's
computer.
3. When the retrieval process is completed,
the vehicle ID information is shown on
the Diagnostic Tool’s display. Use the
UP
and DOWN buttons, as
necessary, to view the entire list.
4. When you have finished viewing the
retrieved vehicle ID information, press the
ENTER/FF
button to return to exit.
Viewing Available Modules
The Diagnostic Tool can retrieve a list of modules supported by the
vehicle under test.
1. From the Vehicle Information menu, use
the UP
and DOWN buttons, as
necessary, to highlight Available Modules,
then press the ENTER/FF
button.
2. A "One moment please..." message
displays while the requested information
is retrieved from the vehicle's computer.
3. When the retrieval process is com-
pleted, a complete list of modules
supported by the vehicle under test is
shown on the Diagnostic Tool’s display.
Use the UP
and DOWN buttons,
as necessary, to view the entire list.
4. When you have finished viewing the list of available modules, press
the ENTER/FF button to the OBD2 DTC screen.
The Diagnostic information retrieved can be transferred to a
personal computer (PC) with the use of an optional Tek-Link
program. See documentation that comes with program for
instructions.
ERASING DIAGNOSTIC TROUBLE CODES (DTCs)
When the Diagnostic Tool’s ERASE function is used to
erase DTCs from the vehicle's on-board computer,
"Freeze Frame" data and manufacturer-specific-enhanced
data are also erased. "Permanent" DTCs ARE NOT erased
by the ERASE function.
If you plan to take the vehicle to a Service Center for repair, DO NOT
erase the codes from the vehicle's computer. If the codes are erased,
valuable information that might help the technician troubleshoot the
problem will also be erased.
