Manual USB 2.0 Frontpanel 3.5 english www.equip-info.
Manual_Page 2 Index 1.0 2.0 3.0 4.0 5.0 6.0 7.0 8.0 Trademarks Introductions Package contents Hardware Requirements System Support How to install your Card Reader to drive bay Pin assignment of USB Cable Driver installations 8.1 Windows 98 driver installation 8.2 Windows 98SE driver installation 8.3 Windows ME driver installation 8.4 Windows 2000 driver installation 8.5 Windows XP driver installation 9.0 10.0 11.0 12.0 13.0 14.
Manual_Page 3 1.0 Trademarks All names and products mentioned below are registered trademarks of their respective companies. 2.0 Introductions The advantage of 3.5 USB2.0 internal Multi I/O Card Reader is to provide a better solution to read or write files for variety of memory cards. It provides tow media slots for Secure Digital card, Multi Media card, Compact Flash, IBM® Micro drive, Smart Media, Memory stick and Memory stick pro memory storage cards.
Manual_Page 4 6.0 How to Install Your Card Reader to drive Bay CAUTION Electrostatic discharge can damaged electronic components. Be sure you are properly grounded before beging any procedure. You can touch a metal part of the computers chassis or power supply unit to discharge any static charge that may have built up inside your body. 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. Turn your computer off and disconnect the power cord. Remove the cover of your computer.
Manual_Page 5 7.0 Pin assignment of USB Cable Dual USB cable pin assignment Single-row USB cable pin assignment This mark identify as the pin1 of USB cable end connector www.equip-info.
Manual_Page 6 IEEE1394 cable pin assignment www.equip-info.
Manual_Page 7 8.0 Driver Installation The card reader need to install application driver for showing media icon on your Windows, you can find the software program in bundle disk and follow next steps to complete the driver installation. NOTE All the driver installation steps may be a little different from this guide when you are using a new upgrade version of OS, in this situation please follow the Windows promt steps to complete the installation procedure. 8.1 Windows 98 driver installation 1.
Manual_Page 8 3. Click Browse to specify the driver location. 4. Insert your driver disc into the CD-ROM drive and path to \Driver\Win98, Click OK to next. 5. Click Next button to continue. www.equip-info.
Manual_Page 9 6. Click Next button to continue. 7. Click Finish button to complete driver installation. 8. Windows will detect reader and display four Removable Disk icons in My Computer, now you can insert your memory card for application. If you have any problem of using media card, please refer to next How to use your media memory card section. www.equip-info.
Manual_Page 10 Windows® 98SE driver installation 1. Turn on your computer, Windows will detect the addition of new hardware and display the following message. Click Cancel button to close this windows. 2. Insert your driver disc into the CD-ROM drive and path to \Driver, double click setup icon. www.equip-info.
Manual_Page 11 3. Click Next button to continue. 4. Click Next button to continue. www.equip-info.
Manual_Page 12 5. Click Next button to continue. 6. Click Next button to continue. www.equip-info.
Manual_Page 13 7. This window shows you that driver has completely installed. You need to restart your computer, Click Finish button. 8. Reboot your system, Windows will detect reader and display four recognizable media icons in My Computer, now you can insert your memory card for application. If you have any problem of using media card, please refer to the next How to use your media memory card section. www.equip-info.
Manual_Page 14 Windows® ME driver installation 1. Close all of your exist executing files. 2. Insert driver disk into the CD-ROM drive. 3. Double click on Driver folder. 4. Double click on Setup icon. 5. Click Next button to continue. www.equip-info.
Manual_Page 15 6. Click Next button to continue. 7. Click Next button to continue. www.equip-info.
Manual_Page 16 8. Click Next button to continue. 9. This windows shows you that driver has completely installed. You need to restart your computer, click Finish button. www.equip-info.
Manual_Page 17 10. Reboot your system, Windows will detect reader and display four recognizable media icons in My Computer, now you can insert your memory card for application. If you have any problem of using media card, please refer to the next How to use your media memory card section. www.equip-info.
Manual_Page 18 Windows® 2000 driver installation 1. Close all of your exist executing files. 2. Insert driver disk into the CD-ROM drive. 3. Double click on Driver folder. 4. Double click on Setup icon. 5. Click Next button to continue. www.equip-info.
Manual_Page 19 6. Click Next button to continue. 7. Click Next button to continue. www.equip-info.
Manual_Page 20 8. Click Next button to continue. 9. This windows shows you that driver has completely installed. You need to restart your computer, click Finish button. www.equip-info.
Manual_Page 21 10. Reboot your system, Windows will detect reader and display four recognizable media icons in My Computer, now you can insert your memory card for application. If you have any problem of using media card, please refer to the next How to use your media memory card section. www.equip-info.
Manual_Page 22 Windows® XP driver installation 1. Close all of your exist executing files. 2. Insert driver disk into the CD-ROM drive. 3. Double click on Driver folder. 4. Double click on Setup icon. 5. Click Next button to continue. www.equip-info.
Manual_Page 23 6. Click Next button to continue. 7. Click Next button to continue. www.equip-info.
Manual_Page 24 8. Click Next button to continue. 9. Click Next button to continue. www.equip-info.
Manual_Page 25 10. This windows shows you that driver has completely installed. You need to restart your computer, click Finish button. 11. Reboot your system, Windows will detect reader and display four recognizable media icons in My Computer, now you can insert your memory card for application. If you have any problem of using media card, please refer to the next How to use your media memory card section. www.equip-info.
Manual_Page 26 9.0 How to use your media memory cards This internal card reader provides two slots for over ten most popular memory cards application. Left slot is for bozh CF and Micro drive, right side is 4 in 1 slot for SD/MMC/MS/SMC media cards. You must insert each memory card in correct slot and do not attemp to insert the memory card in reverse direction by force. Please refer to the following description. 1.
Manual_Page 27 10.0 How to format your memory card You can format the memory card like as format remove disk, but in some memory card such as memory stick and SD card, you must be sure the write protected switch is disable. 11.0 Indicator Description The card reader provides a R/W (read/write) status indicator for card slot diagnosis. Normally the R/W indicator is off, when data is transmitting between PC and memory card, the R/W LED will turn flash.
Manual_Page 28 12.0 Booting from CF memory This reader can boot from CF slot like as Floppy disk drive, but your system BIOS must support and has changed to booting from USB device setting, otherwise you can´t boot from this reader. Please see the following example to check your BIOS CMOS setting and change First Boot Device to USB-HDD. NOTE The BIOS setup utility is constantly update, the following BIOS screen descriptions are for reference purposes only and may not reflect your BIOS screen exactly.
Manual_Page 29 13.0 How to swap your front bezel If you want to change bezel to different color, find a stylus or pin-like tool to press the plastic-clip in both sides and take off the front bezel. Then you can replace another bezel. 14.0 Application of media I/O www.equip-info.
