95
Connecting with a USB Cable and Projecting (USB Display EB-1735W/1725/1723 only)
By using a commercially available USB cable to connect the projector to a
Windows computer you can project images from the computer. This function
is called USB Display. Simply by connecting via a USB cable, images from
the computer can be displayed.
Connecting
Attention
Connect the projector directly to the computer and not via a USB
hub.
Procedure
Connects to the power cable
(supplied).
Turn the projector on.
Open the A/V mute slide.
Connects to the USB cable.
Turn the computer on.
s "Connecting for the first time" p.96
s "From the second time" p.97
Using the control
panel
Using the remote
control
Beep
q
• Audio is output even when
an audio cable is not
connected. If you don't want
to output audio from the
projector, on the computer
click "EPSON Projector" -
"EPSON USB Display" -
"EPSON USB Display Vx.x
Setting", and uncheck
"Output audio from the
projector".
• If you are running the
application software such as
Windows Media Player
before you connect a USB
cable, audio may not be
output from the projector.
To output audio from the
projector, close the
application software, and
then restart it.
