Saving a User's Logo
87
D
Move the box to select the part of the image to use
as the user's logo.
E
When "Select this image?" is displayed, select
"Yes".
F
Select the zoom factor from the zoom setting
screen.
G
When the message "Save this image as the User's
Logo?" is displayed, select "Yes".
The image is saved. After the image has been saved, the message
"Completed." is displayed.
Using the remote control Using the control panel
q
You can save at up to 400
^
300 dots in size.
q
• Once a user's logo has been saved, the logo cannot be
returned to the factory default.
•
Saving the user's logo may take approximately 15 seconds.
Do not use the projector or any connected equipment while it
is saving, otherwise malfunctions may occur.
