Replacing Consumables
84
Replacing the Air Filter
f Air filter replacement period
It is time to replace the air filter when:
• The air filter has been turned brown.
• The message is displayed even though the air filter has been
cleaned.
f How to replace the air filter
The air filter can be replaced even when the projector is suspended from a
ceiling.
A
After you turn off the projector's power and the
confirmation buzzer beeps twice, disconnect the
power cable.
B
Remove the air filter.
Grip the air filter cover tab and pull it straight to outside.
C
Install the new air filter.
Slide the air filter from the outside and press in until it firmly clicks
into place.
Procedure
q
Dispose of used air filters properly in accordance with your
local regulations.
Material of the frame part: Polyphenylene ether,
Polystyrene
Material of the filter part: Polyurethane foam
