Replacing Consumables
81
f How to replace the lamp
The lamp can be replaced even when the projector is suspended from a
ceiling.
A
After you turn off the projector's power and the
confirmation buzzer beeps twice, disconnect the
power cable.
B
Wait until the lamp has cooled down, then remove
the lamp cover.
Loosen the lamp cover fixing screw with the screwdriver supplied
with the new lamp or a + head screwdriver. Then slide the lamp
cover straight forward and lift it to remove.
Warning
When replacing the lamp because it has stopped illuminating, there
is a possibility that the lamp may be broken.
If replacing the lamp of a projector which has been installed on the
ceiling, you should always assume that the lamp is broken, and you
should stand to the side of the lamp cover, not underneath it.
Remove the lamp cover gently.
Caution
Wait until the lamp has cooled down sufficiently before removing
the lamp cover. If the lamp is still hot, burns or other injuries may
result. It takes about one hour after the power has been turned off
for the lamp to be cool enough.
Procedure
