List of Functions
45
Extended Menu
EB-1735W/1725/1723 EB-1730W/1720
Sub Menu Function
Display You can make settings related to the projector's display.
Messages: You can set whether or not (On/Off) to display the source name when you change the input source, the color mode name when you
change the color mode, a message when no image signal is input, and so on.
Display Background*: You can set the screen status for when no image signal is available to "Black", "Blue", or "Logo".
Startup Screen*: You can set whether or not (On/Off) the startup screen (the image projected when starting the projector) is displayed.
A/V Mute*: You can set the screen displayed during A/V Mute as "Black", "Blue", or "Logo".
User's Logo
*
You can change the user's logo that is displayed as a background and displayed during A/V Mute. s p.86
Projection You can set from the following according to the way the projector is setup. s p.77
Front" "Front/Ceiling" "Rear" "Rear/Ceiling"
You can change the setting as follows by pressing down the [A/V Mute] button on the remote control for about five seconds.
Front"W"Front/Ceiling"
Rear"W"Rear/Ceiling"
* When "User's Logo Protect" is set to "On" in "Password Protect", settings relating to user's logo cannot be changed. You can make changes after setting "User's
Logo Protect" to "Off". s p.33
