List of Functions
44
User Button You can select the item assigned from the configuration menu with the remote control's [User] button. By pressing the button the assigned menu
item selection/adjustment screen is displayed, allowing you to make one-touch settings/adjustments. You can assign one of the following six items
to the [User] button.
Brightness Control, Info, Progressive, Test Pattern, Multi-screen, or Resolution
Te s t Pa t t e r n When the projector is setup, a test pattern is displayed so that you can adjust the projection without connecting other equipment. While the test
pattern is displayed, zoom, focus adjustments, and keystone correction can be performed.
To cancel the test pattern, press the [Esc] button on the remote control or the control panel.
Reset You can reset all adjustment values on the "Settings" menu to their default settings, except for "User Button".
To return all menu items to their default settings, see s p.61
Sub Menu Function
