Functions for Enhancing Projection
24
Pointer Function (Pointer)
This allows you to move a pointer icon on the projected image, and helps
you draw attention to the area you are talking about.
A
Display the pointer.
Each time you press the button, the pointer appears or disappears.
B
Move the pointer icon.
When pressed in conjunction with the adjacent [ ] button, the pointer
can be moved diagonally in addition to up/down and left/right.
Procedure
Remote control
q
You can choose from three different kinds of pointer
icon
( · · ) in "Settings
" - "Pointer Shape" from the
configuration menu.
s
p.43
Pointer icon
Remote control
