Functions for Enhancing Projection
23
Through Projects at the resolution of the input image size
to the center of the screen. This is ideal for
projecting clear images.
If the image resolution exceeds 1280 ^ 800, the
edges of the image are not projected.
When an 800 ^ 600 signal is
input
When a 1400 ^ 1050 signal is
input
q
When projecting computer images, if parts of the image are missing or it cannot project everything, set "Wide" or "Normal" in
"Resolution" from the configuration menu depending on the size of the computer panel.
s
p.41
Set Values Operation Projection example
