Display format Refresh rate (in Hz) Resolution (in pixels)
UXGA 60 1600 × 1200
(PowerLite X17/X21/W17)
WSXGA+ 60 1680 × 1050
(PowerLite W17)
SDTV (480i/480p) 60 720 × 480
SDTV (576i/576p) 50 720 × 576
HDTV (720p) 50/60 1280 × 720
HDTV (1080i) 50/60 1920 × 1080
HDTV (1080p) 24/30/50/60 1920 × 1080
* Wide resolution only
Parent topic: Technical Specifications
USB Display System Requirements
Your computer system must meet the system requirements here to use the projector's USB Display
software.
Requirement Windows Mac
Operating system Windows 2000 (Service Pack 4 only) Mac OS X 10.5.8 (32-bit); Mac OS X
10.6.x, 10.7.x, or 10.8.x (32- and 64-
Windows XP Professional, Home
bit)
Edition, and Tablet PC Edition (32-bit);
except for Service Pack 1
Windows Vista Ultimate, Enterprise,
Business, Home Premium, and Home
Basic (32-bit)
Windows 7 Ultimate, Enterprise,
Professional, and Home Premium (32-
and 64-bit); Home Basic and Starter (32-
bit)
Windows 8, Windows 8 Enterprise and
Pro (32- and 64-bit)
