Setting Options Description
Keystone H/V Keystone Adjusts image shape to
rectangular (horizontally and
Quick Corner
vertically)
H/V Keystone: lets you manually
correct horizontal and vertical
sides
Quick Corner: select to correct
image shape and alignment
using an on-screen display
Zoom Varying levels available Adjusts the size of the projected
(PowerLite S17)
Control Panel Lock Full Lock Controls projector button locking
to secure the projector
Partial Lock
Full Lock: locks all buttons
Off
Partial Lock: locks all buttons
except the power button
Off: no buttons locked
Pointer Shape Three shapes available Changes the shape of the remote
control pointer feature
