Screen or image size Projection distance (1) Offset from lens center (2)
Wide to Tele
80 inches (203 cm) 97 to 157 inches 1.1 inch (3 cm)
(245 to 400 cm)
100 inches (254 cm) 121 to 197 inches 1.4 inches (3 cm)
(307 to 501 cm)
150 inches (381 cm) 182 to 296 inches 2 inches (5 cm)
(463 to 753 cm)
200 inches (508 cm) 243 to 396 inches 2.7 inches (7 cm)
(618 to 1005 cm)
250 inches (635 cm) 305 to 495 inches 3.4 inches (9 cm)
(774 to 1257 cm)
275 inches (699 cm) 335 to 545 inches 3.7 inches (10 cm)
(852 to 1383 cm)
Parent topic: Projector Placement
Projector Connections
You can connect the projector to a variety of computer, video, and audio sources to display
presentations, movies, or other images, with or without sound.
• Connect any type of computer that has a standard video output (monitor) port or an HDMI port.
• For video projection, connect devices such as DVD players, gaming consoles, digital cameras, and
camera phones with compatible video output ports.
• If your presentation or video includes sound, you can connect audio input cables, if necessary.
• For presentations or slide shows without a computer, you can connect USB devices (such as a flash
drive or camera) or an optional document camera.
Caution: If you will use the projector at altitudes above 4921 feet (1500 m), turn on High Altitude Mode
to ensure the projector's internal temperature is regulated properly.
Connecting to Computer Sources
