Display format Refresh rate (in Hz) Resolution (in pixels)
TV (NTSC) 60 720 × 480
TV (PAL) 50/60 720 × 576
TV (SECAM) 50 720 × 576
Component video
SDTV (480i) 60 720 × 480
SDTV (576i) 50 720 × 576
SDTV (480p) 60 720 × 480
SDTV (576p) 50 720 × 576
HDTV (720p) 50/60 1280 × 720
HDTV (1080i) 50/60 1920 × 1080
HDMI input signals
VGA 60 640 × 480
SVGA 60 800 × 600
XGA 60 1024 × 768
WXGA 60 1280 × 800
SXGA 60 1280 × 960
60 1280 × 1024
SXGA+ 60 1400 × 1050
UXGA 60 1600 × 1200
SDTV (480i/480p) 60 720 × 480
SDTV (576i/576p) 50 720 × 576
HDTV (720p) 50/60 1280 × 720
HDTV (1080i) 50/60 1920 × 1080
HDTV (1080p) 24/30/50/60 1920 × 1080
** Available only with PowerLite D6155W when using the Wide option as the Resolution setting
Parent topic: Technical Specifications
