Supported Video Display Formats
For best results, your computer monitor or video card resolution should be set to display in the
projector's native resolution. However, your projector includes Epson's SizeWise chip that supports other
computer display resolutions, so your image will be resized to fit automatically.
Your computer's monitor or video card refresh rate (vertical frequency) must be compatible with the
projector. (See your computer or video card manual for details.)
The table here lists the compatible refresh rate and resolution for each compatible video display format.
Display format Refresh rate (in Hz) Resolution (in pixels)
Computer signals (analog RGB)
VGA 60/72/75/85 640 × 480
SVGA 56/60/72/75/85 800 × 600
XGA 60/70/75/85 1024 × 768
WXGA 60 1280 × 768
60 1360 × 768
60/75/85 1280 × 800
SXGA 70/75/85 1152 × 864
60/75/85 1280 × 960
60/75/85 1280 × 1024
SXGA+ 60/75 1400 × 1050
WXGA+ 60/75/85 1440 × 900
UXGA 60 1600 × 1200
WSXGA+* 60 1680 × 1050
MAC13" 67 640 × 480
MAC16" 75 832 × 624
MAC19" 75 1024 × 768
59 1024 × 768
MAC21" 75 1152 × 870
