Setting Options Description
Keystone H/V Keystone Adjusts image shape to
rectangular (horizontally and
Quick Corner
vertically)
H/V Keystone: lets you manually
correct horizontal and vertical
sides, or turn automatic
correction (PowerLite 1776W) on
or off
Quick Corner: select to correct
image shape and alignment
using an on-screen display
Split Screen Screen Size Divides the viewing area
horizontally and displays two
(PowerLite Source
images side-by-side (press Esc
1761W/1771W/1776W)
Swap Screens
to cancel split screen display)
Audio Source
Control Panel Lock Full Lock Controls projector button locking
to secure the projector
Partial Lock
Full Lock: locks all buttons
Off
Partial Lock: locks all buttons
except the power button
Off: no buttons locked
Pointer Shape Three shapes available Changes the shape of the remote
control pointer feature
Power Consumption Normal Selects the brightness mode of
the projector lamp
ECO
Normal: sets maximum lamp
brightness
ECO: reduces lamp brightness
and fan noise, and saves power
and lamp life
106
