4. Second Step
4.2 Ethernet Connection of Development PC and Controller
EPSON RC+ 5.0 User’s Guide
Ethernet Communication
ROBOT CONTROLLER RC90
(EPSON RC+5.0)
Setup & Operation: LAN (Ethernet) Port
4.3 Connection of Option TP2
Controller RC90
TP2
TP2
Connection
Robot Controller RC90
Setup & Operation: TP Port
RC90/RC180 Option Teach Pendant TP2
Function & Installation: Installation
Safety and Installation (RC90 / EPSON RC+5.0) Rev.6
58
