2. Installation
System Example
*1 EPSON RC+ 5.0 supports the following OS.
Windows XP Professional Service Pack 3 (EPSON RC+ 5.0 Ver.5.2.0 SP3 or after is required.)
Windows Vista Business Service Pack 2 (EPSON RC+ 5.0 Ver.5.3.1 or after is required.)
Windows 7 Professional (EPSON RC+ 5.0 Ver.5.3.4 or after is required.)
RC90
Windows *1
(XP, Vista, 7)
PC
TP2
(Option)
LS series
Operation Panel
Motion Controller
Expansion
I/O Board
Fieldbus
- PROFIBUS-DP
- DeviceNet
- CC-Link
RS-232C Board
USB2.0
or
Ethernet
- Standard I/O
- Remote I/O
- Ethernet
- RS-232C
PLC (Sequencer)
EPSON RC+ 5.0
Software
Option
Requires preparation by uses
Option Standard
CV1
Ethernet
Safety and Installation (RC90 / EPSON RC+5.0) Rev.6
20
