1. Safety
Manipulator
Location Label Note
A
Before loosening the base mounting
screws, hold the arm and secure it tightly
with a band to prevent hands or fingers
from being caught in the Manipulator.
For installation and transportation of
robots, follow the directions in this
manual.
B
Do not enter the operation area while the
Manipulator is moving. The robot arm
may collide against the operator. This is
extremely hazardous and may result in
serious safety problems.
C
Hazardous voltage exists while the
Manipulator is ON. To avoid electric
shock, do not touch any internal electric
parts.
D
You can catch your hand or fingers
between the shaft and cover when
bringing your hand close to moving parts.
Manipulators with bellows do not have
this label for no danger of your hand or
fingers being caught
12 Safety and Installation (RC90 / EPSON RC+5.0) Rev.6
