Specifications Page 195
Interfaces
Parallel interface
Forward channel
Reverse channel
Specification Description
Data format 8-bit parallel, IEEE-1284 compatibility mode
Synchronization STROBE pulse
Handshake timing BUSY and ACKNLG
signals
Signal level TTL compatible
Connector 57-30360 Amphenol connector or equivalent
Specification Description
Transmission mode IEEE-1284 Nibble mode
Adaptable connector 57-30360 Amphenol connector or equivalent
Synchronization Refer to the IEEE-1284 specification
Handshaking Refer to the IEEE-1284 specification
Signal level IEEE-1284 Level 1 device
Data transmission
timing
Refer to the IEEE-1284 specification
