Event ID code Cause and solution
0479 A projector system error has occurred. Turn the projector off and then on again.
04FF
0891 Cannot find an access point with the same SSID. Set your computer, access point,
and projector to the same SSID.
0892 The WPA/WPA2 authentication type does not match. Make sure the wireless
network security settings are correct.
0893 The WEP/TKIP/AES encryption type does not match. Make sure the wireless
network security settings are correct.
0894 Communication with unauthorized access point was disconnected. Contact your
network administrator.
0898 Failed to acquire DHCP. Make sure the DHCP server is operating correctly. If you
are not using DHCP, turn off the DHCP setting in the Network menus.
0899 A communication error has occurred. Try restarting the EasyMP Network Projection
program and restarting your projector. If that does not solve the problem, contact
Epson for help.
089A The EAP authentication type does not match the network. Check the wireless LAN
security settings and make sure that the security certificate is installed correctly.
089B EAP server authentication failed. Check the wireless LAN security settings and
make sure that the security certificate is installed correctly.
089C EAP client authentication failed. Check the wireless LAN security settings and make
sure that the security certificate is installed correctly.
089D Key exchange failed. Check the wireless LAN security settings and make sure that
the security certificate is installed correctly.
0B01 The internal storage could not be detected correctly. Select Delete All Internal Data
in the Basic menu under Whiteboard Settings. Turn off the projector and disconnect
the power cord, then reconnect the power cord and turn the projector back on. If that
does not solve the problem, contact Epson for help.
0BFF An error has occurred in the whiteboard function. Restart the projector.
Parent topic: Projector Information Display - Info Menu
