Setting Options Description
Sleep Mode On Automatically places the
projector in standby mode after
Off
an interval of inactivity
Sleep Mode Timer 1 to 30 minutes Sets the interval for Sleep Mode
A/V Mute Timer On Automatically turns off the
projector after 30 minutes if A/V
Off
Mute is enabled
Standby Mode Communication On Enable this setting to allow the
following operations to occur
Communication Off
when the projector is in standby
mode:
• Monitor and control the
projector over a network
• Output audio and video to an
external device (A/V Output
must be set to Always On)
ECO Display On Displays a leaf icon in the bottom
left corner of the projected screen
Off
to indicate the power-saving
status when the lamp brightness
changes
Parent topic: Adjusting the Menu Settings
Related references
Projector Lamp Specifications
