Setting Options Description
Sync. Varying levels available Adjusts signal to eliminate
fuzziness or flickering in
computer images
Position Up, down, left, right Adjusts the image location on the
screen
Progressive Off Sets whether to convert
interlaced-to-progressive signals
Video
for certain video image types
Film/Auto
Off: for fast-moving video images
Video: for most video images
Film/Auto: for movies, computer
graphics, and animation
Noise Reduction Off Reduces flickering in analog
images in two levels
NR1
NR2
HDMI Video Range Auto Sets the video range to match the
setting of the device connected to
Normal
the HDMI input port
Expanded
Auto: detects the video range
automatically
Normal: normally for images from
a device other than a computer;
can also be selected if the black
areas of the image are too bright
Expanded: normally for images
from a computer; can also be
selected if the image is too dark
237
