Contact Apple for compatible adapter options. Older Mac computers (2009 and earlier) may not
support audio through the HDMI port.
• To receive an HDMI signal via MHL, you need an MHL-compatible device, an MHL cable or an HDMI
cable and an MHL adapter compatible with your device. Devices with an integrated MHL connector
may not require a cable.
• To sync additional BrightLink Pro projectors together, you will need a stereo mini cable or the remote
control cable set (ELPKC28).
• To power the Control Pad from the projector, you will need the remote control cable set (ELPKC28).
• To project with audio from certain ports, you may need a commercially available audio cable
compatible with your device. See your local computer or electronics dealer for purchase information.
• If you did not purchase a mount that included a VGA cable, you may need a VGA computer cable. You
can purchase one from Epson or an authorized Epson reseller.
Parent topic: Projector Features
Optional Equipment and Replacement Parts
You can purchase screens, other optional accessories, and replacement parts from an Epson authorized
reseller. To find the nearest reseller, call 800-GO-EPSON (800-463-7766). Or you can purchase online
at epsonstore.com (U.S. sales) or epson.ca (Canadian sales).
Epson offers the following optional accessories and replacement parts for your projector:
Option or part Part number
Genuine Epson replacement lamp (ELPLP80) V13H010L80
Replacement air filter (ELPAF40) V13H134A40
Quick wireless connection USB key (ELPAP09) V12H005M09
Promethean ActivInspire software V12HPSW001
SMART Notebook software V12HSSW020
Mimio MimioStudio Software for BrightLink Projectors V12HMSS020
Wall mount (ELPMB43) V12H675020
Table projection mount (ELPMB29) V12H516020
Epson DC-06 document camera (ELPDC06) V12H321005
Epson DC-11 document camera (ELPDC11) V12H377020
