Supported Printer Types
You can connect to a printer with the type and command language described here.
Note: Scanning is only supported from Epson All-in-One printers over a USB connection.
Printer type Command language Scanner USB Network
connection connection
Single- ESC/Raster No Yes No
function
printer
Single- ESC/P-R No Yes Yes
function
printer
Multi-function ESC/Raster Yes Yes No
printer
Multi-function ESC/P-R Yes Yes Yes
printer
Laser ESC/Page, ESC/Page- No No Yes
Color
Laser PCL6-compatible No No Yes
Parent topic: Connecting a Printer to the Control Pad
Related tasks
Selecting Whiteboard Print Settings
Connecting to a Document Camera
You can connect a document camera to your projector to project images viewed by the camera.
Depending on your Epson document camera model, do one of the following to connect the document
camera to your projector:
• For the Epson DC-06 document camera, locate the USB cable that came with the camera and
connect it to the to the projector's USB-A port and to the document camera's USB Type B port.
• For the Epson DC-11 document camera, connect it to the projector's Computer or Video port and to
the corresponding port on the document camera. See the document camera manual for details.
