Projector Setup Settings - ECO Menu
Settings on the ECO menu let you customize projector functions to save power. When you select a
power-saving setting, a leaf icon appears next to the menu item.
Setting Options Description
Power Consumption Auto Selects the brightness mode of
the projector lamp
Normal
Auto: sets the projector to sense
ECO
the optimum lamp brightness and
adjust the lamp brightness
accordingly
Normal: sets maximum lamp
brightness
ECO: reduces lamp brightness
and fan noise, and saves power
and lamp life
Light Optimizer On When Power Consumption is
set to Normal, the lamp
Off
brightness is adjusted based on
the projected image; you can set
this option for each color mode
