Option or part Part number
Epson DC-12 document camera (ELPDC12) V12H594020
Epson DC-20 document camera (ELPDC20) V12H500020
PowerLite Pilot 2 (ELPCB02) V12H614020
Active speakers (ELPSP02) V12H467020
Additional interactive pen A (ELPN04A) (orange) V12H666010
Additional interactive pen B (ELPN04B) (blue) V12H667010
Replacement set of 6 pen tips (ELPPS02) V12H668010
Interactive Pen Extension (ELPPE01) V12H590001
USB extension cable V12H525001
Remote control cable set (ELPKC28) V12H005C28
On Wall Cable Management Kit ELPCK01
Kensington security lock ELPSL01
Touch Unit attachment mount (BrightLink Pro 1430Wi) ELPPT05
90-inch whiteboard V12H468002
96-inch whiteboard V12H468001
6 ft. (1.8 m) VGA computer cable F3H982-06
10 ft. (3.0 m) VGA computer cable F3H982-10
10 ft. (3.0 m) Component-to-VGA video cable ELPKC19
In addition to the accessories listed above, 1-year and 2-year extended service plans are available.
Parent topic: Projector Features
Warranty and Registration Information
Your projector comes with a basic warranty that lets you project with confidence. For details, see the
warranty that came with your projector.
In addition, Epson offers free Extra Care Road Service. In the unlikely event of an equipment failure, you
won’t have to wait for your unit to be repaired. Instead, Epson will ship you a replacement unit anywhere
in the United States, Canada, or Puerto Rico. See the Extra Care Road Service brochure for details.
