Note: Easy Interactive Driver must be installed and running to use Easy Interactive Tools on a Mac.
Requirement Windows Mac
Operating system Windows XP Professional SP2 or later, OS X 10.5.x, 10.6.x, OS X 10.7.x,
Home Edition 10.8.x, 10.9.x (32-bit)
OS X 10.6.x, OS X 10.7.x, 10.8.x,
Windows Vista Ultimate, Enterprise,
10.9.x (64-bit)
Business, Home Premium, and Home
Basic (32-bit)
Windows 8.x Pro, Enterprise, Windows 7
Ultimate, Enterprise, Professional, Home
Premium, and Home Basic (32- and 64-
bit)
CPU Intel Pentium M 1.6 GHz or faster (Core2 Power PC G4 1.5 GHz or faster
Duo 1.2 GHz or faster recommended) (Core Duo 1.83 GHz or faster
recommended)
Memory 512MB or more (1G or more recommended)
Hard disk space 100MB or more
Display Resolution between 1024 × 768 and 1920 × 1200, 16-bit color or greater
Parent topic: Using BrightLink With a Computer
Related concepts
Easy Interactive Tools
Switching to PC Interactive Mode
You can easily switch between PC Free annotation and PC interactive modes. Although you can use
both pens in PC interactive mode, this may cause interference in some applications that only support
one pen. To avoid interference, turn off the unused pen or move it away from the projection surface.
• To switch to PC interactive mode, select the Pen mode icon on the toolbar, then select the
Mouse icon.
• To switch back to annotation mode, select the Mouse icon, then select the Pen mode icon.
Parent topic: Using BrightLink With a Computer
