Owner's manual
Table Of Contents

Instructions for use
Eppendorf Serological Pipets
English (EN)
Instruc tions for us e Eppendorf Serological Pipetsseeon p.Fig.Tab .p.
English (EN )
1 Operating instructions
1.1 Using this manual
Before using the consumables for the first time, read these instructions for use and the operating manual of
the device that you use the consumables with.
2 Product description
2.1 Main illustration
2.2 Overview of Eppendorf Serological Pipets with color codes
1Outlet opening
2Graduation
3Zero point
4 Negative graduation
5Nominal volume
6 Increment
7Pipette type
8 Test temperature
9 Color code
10 Filter
11 Aspiration area
Nominal volume 1 mL 2 mL 5 mL 10 mL 25 mL 50 mL
Color code
Accuracy [± mL] 0.02 0.04 0.1 0.2 0.5 1
Graduation [mL] 0.01 0.02 0.1 0.1 0.2 0.5
Negative graduation [mL] -0.2 -0.8 -3 -3 -9 -6
Length [mm] 277 277 338 338 343 343
Diameter at the aspiration area [mm]
4.6 6.4 8.2
7.8 8.3 8.3
Max. diameter [mm] 9.9 14.6 18.6
10 mL in 1/10 TD 20° C
1
2
3
4
5
6
7
8
9
10
10 mL in 1/10 TD 20° C
5678
1
2
4
3
9 10 11
