User`s manual
.A=JKHAI
Page 2-2
- PCI Bus IDE Port with PIO/Ultra DMA-66/100 x 2 (up to 4 devices)
- Extra IDE Port by HPT372 with Ultra DMA-100/133and IDE RAID x 2
(up to 4 devices)
* Supports JBOD function (Just a Bunch of Disks). JBOD are a group of
hard disks in a computer that are not configured in a RAID.
!!
!!
!
Onboard LAN
- Integrate 10/100Mb fast Ethernet controller in Realtek RTL8100B Lan
by RJ-45 connector
!!
!!
!
I/O CONNECTOR
- PS/2 mouse and keyboard
- COM1, COM2
- LPT (printer)
- Audio-in/out, MIC
- Game port by extra cable
- RJ-45 jack
- USB connector x 6 (two optional via mainboard front panel USB
connector). USB supports USB 2.0 specification. The USB3 can support
Bluetooth Module.
!!
!!
!
IEEE 1394 (Optional)
- Integrated OHCI 1.1 1394 controller
- Supports two 400Mbps 1394a ports
!!
!!
!
BIOS
- Award Plug & Play BIOS
!!
!!
!
Built-in AC 97 Digital Audio by Realtek ALC650 (6 channel)
- Compliant with AC97 2.2 specification
- Six-channel, slot selectable DAC (Digital Analog Converter) output for
multi-channel applications
- Supports digital SPDIF function
- Supports game and MIDI port
