User's Manual

CDMA FWP SXP-2080

Technical & User Manual

Explain on Menu Tree

0. Hidden Menu

1. System Info 1. Debug Screen

If you choose the debug screen, you can show to the information of RSSI, Ec/Io,Rx/Tx Power.

Ex) S 14846 (S:System ID) C 0283 (C:Channel)

N 00001(N:Network ID)

R 100 (R:RSSI / dBm) E 05 (E:Ec/Io)

PN 122 Tx -73 (Tx power dBm)

1. System Info 2. Test Call

In the Test call mode, you can call as below.

1. new 8k Markov,

2. new 13k Markov,

3. 8k loopback,

4. 13k loopback

5. SO54 Markov,

6. SO55 loopback

2. Audible Tone

There is 4-type of dial tone type for country.

1. Korea

2. Latin America

3. East Europe

4. China / Siria

5. Nicaragua

6. India

3. Others Menu (Lock Code : 175930 ) 1. Emergency #(Number)

The emergency number can input maximum by 3 and limited area in country.

1. Press the ‘Edit’ Softkey

2. Enter the emergency number

3. Press the navigation key, You can show the other number of emergency.

4. Press the ‘Save’ softkey. And Saving the emergency number.

3. Others Menu (Lock Code : 175930 ) 2. User Care #(Number)

The usercare number can input maximum by 3 and limited area in country.

1. Press the ‘Edit’ Softkey

2. Enter the user care number

3. Press the navigation key, You can show the other number of user care.

4. Press the ‘Save’ softkey. And Saving the user care number.

3. Others Menu (Lock Code : 175930 ) 3. Mirroring

In the Mirroring menu, you can backup/restore system configuration of phone.

1. Press the navigation key you can show the option of mirroring that kind of ‘Do mirroring’ or ‘Do Restore’

2. It choose the item (Do Mirroring or Do Restore)

3. Press the ‘Ok’ softkey, Runing the mirroring function
