TM Wireless Stereo Speaker OWNER’S MANUAL
Thank You For Choosing Eos Wireless! We hope you will find much enjoyment from our new wireless audio system. Please read the entire contents of this owner’s manual. It is filled with reference information that will allow you to get the most from your new Eos system. If you have any questions, please check our web site at www.eoswireless.com/productsupport or call us at 877-465-3927. Your Total Satisfaction – Eos Job #1 Congratulations on your purchase of the Eos Digital Wireless Multi-Room Audio System.
Table Of Contents Important Safety Instructions........................................................................................................... 4 A Consumer Guide to Product Safety............................................................................................ 5 Safety Instructions.......................................................................................................................... 5 FCC Information...................................................................
Important Safety Instructions Please take the time to follow the instructions in this owner’s guide carefully. It will help you set up and operate your system properly and enjoy all of the advanced features. Please save this owner’s guide for future reference. WARNING: The grill and screws around the subwoofer can get hot. Care should be taken when touching this area. WARNING: To reduce the risk of fire or electrical shock, do not expose the product to rain or moisture.
A Consumer Guide to Product Safety Safety Instructions 1. Read instructions before using this product. 2. Keep these instructions for future reference. 3. Heed all warnings on the product and in the owner’s guide. 4. Follow all instructions. 5. Do not use this apparatus near water or moisture. Do not use this product near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, near a swimming pool, or anywhere else that water or moisture are present. 6.
A Consumer Guide to Product Safety 15. Do not let objects or liquids enter the product as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. 16. Use proper power sources - Plug the product into a proper power source, as described in the operating instructions or as marked on the product.
A Consumer Guide to Product Safety Warranty Your Eos digital Wireless Speaker system is covered by a one-year limited warranty. For details see the Eos Warranty section of this manual. To register your product, go online to: www.eoswireless.com/registration Technical Information Power rating: Input - 100-240 VAC 50-60Hz Output - 15 VDC 1.3A Wireless specifications: 150 ft indoors / 300 ft outside Range 1.
Quick Start Digital Wire less Mult Parts Checklist 1. This Owner’s Manual OWNERS 2.
Controls and Functions Wireless Stereo Speaker Controls & Functions Integrated Power Adapter Allows wireless speaker to mount to wall jack, or remove for table or countertop placement. Antenna Power/Status LED Illuminates when the wireless speaker is linked to the base station, blinks when the there is no link to the base station. Volume/Power Knob Turns on power to the wireless speaker and controls volume.
Using Your Eos System Muting the Base Station Speakers: The MUTE button, located on the Eos Base Station, allows you to mute the Base Station speakers. When the speaker to the base unit is muted, the blue LED source indicator light (iPod or Aux) will flash. MUTE E SOURC iPod Turning the wireless transmitter On/Off: The “wireless transmitter” button, located in the center of the Base Station, allows you to turn OFF transmission to all Wireless Speakers/Receivers.
Using Your Eos System Wireless Speakers/Receivers: All Eos Base Stations, Wireless Speakers and Receivers have the same ID setting. This is done so Speakers/Receivers will automatically link with any Base Station. The Base Station will link with the first 4 Wireless Speakers that it detects. digital wireless speakers 1 2 3 4 The LED indicators on the Base Station (labeled as, “digital wireless speakers”) indicate the number of Wireless Speakers/Receivers linked to your Base Station.
Using Your Eos System Setting a Unique ID: To give your Base Station and Speakers/Receivers a Unique ID do the following: 1. Disconnect the power supply from the Base Station 2. Using the Volume Control Switch, turn off all power to the Wireless Speakers/Receivers that you wish to link. 3. Reconnect the power supply to the Base Station 4.
Using Your Eos System Resetting the ID to Default: To reset the Base Station and Speaker/Receiver’s ID back to the factory default, do the following: 1. Disconnect the power supply from the Base Station 2. Using the Volume Control Switch, turn off all power to the Wireless Speakers/Receivers. 3. While pressing and holding the “LINK” button on the rear of the Base Station reconnect the power supply from the Base Station. 4.
Using Your Eos System Wireless Speaker Operation The Wireless Speaker can be used as a wall-mounted speaker (power supply nested in the back of the speaker enclosure) or as a desktop/bookshelf speaker (power supply removed from the speaker enclosure.) Powering Your Wireless Speaker: 1. Plug your Wireless Speaker into any wall outlet located no more than 150 feet from the Eos Base Station. 2. Turn the Volume Knob clockwise to power the Wireless Speaker.
Using Your Eos System Removing the Integrated Power Supply From the Wireless Speaker: To use your Wireless Speaker on a desktop/bookshelf, remove the power supply from the wireless speaker by following these steps: 1. Press down on the top of the power supply. The swivel plate beneath the power supply will make a “click” sound and rotate outward. 2. Rotate adapter forward and remove the power supply from the enclosure.
Using Your Eos System Reattaching the Power Supply to the Wireless Speaker: 1. Coil the cord around your hand. 2. Place the coil of cord in the bottom of the cavity. 3. Press lower edge of swivel plate to rotate forward 4. Insert the power supply into the cavity leaning forward. 5. Press down on the top of the power supply. 6. Rotate the power supply back to a vertical position (making sure to lock the tab at the top of the speaker cabinet with the groove at the top of the power supply.
Using Your Eos System Adding Additional Wireless Speakers/Receivers: You can link up to 4 Wireless Speakers, placed up to 150 ft away from the Base Station. All Eos Base Stations, Wireless Speakers/Receivers leave the factory with the same ID setting. This is done so Speakers/Receivers will link with any Base Station right out of the box. A new Wireless Speaker will automatically link with your Base Station as soon as it is turned on.
Troubleshooting Symptom Wireless Speaker Possible Problem Solution Unit does not respond (blue Antenna LED is off ) AC adapter is not plugged into wall outlet or the connector in the back of the Wireless Speaker is not connected properly Unplug and re-plug the connector to the back of the Wireless Speaker No Sound (blue Antenna LED is solid) Volume to low Turn volume control clockwise No audio playing at Base Station Confirm playback by listening the to speakers on the Base Station.
Warranty Limited Warranty IntelliTouch warrants this product to be free from manufacturing defects in material and workmanship under normal use and conditions for a period of 1-year from date of original purchase in the United States. In order to validate your warranty, you must register your product by going on-line (www.eoswireless.com), or by calling 877-465-3927 between Monday through Friday, 8:30AM to 5PM Pacific Time.
Warranty THIS WARRANTY IS NON-TRANSFERABLE AND APPLIES ONLY TO THE ORIGINAL PURCHASER AND DOES NOT EXTEND TO SUBSEQUENT OWNERS OF THE PRODUCT. ANY APPLICABLE IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED IN DURATION TO A PERIOD OF THE EXPRESS WARRANTY AS PROVIDED HEREIN BEGINNING WITH THE DATE OF ORIGINAL PURCHASE AT RETAIL AND NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, SHALL APPLY TO THIS PRODUCT THEREAFTER.
