I/O PIN LISTING
Pin No. Pin Name Type Description
1
PIO21
Digital: Bidirectional with programmable
strength internal pull- up/pull-down
Programmable I/O line 21.
Alternative function : PCM_DOUT[2]
2
PIO20
Digital: Bidirectional with programmable
strength internal pull- up/pull-down
Programmable I/O line 20.
Alternative function : PCM_DOUT[1]
3
PIO19
Digital: Bidirectional with programmable
strength internal pull- up/pull-down
Programmable I/O line 19.
Alternative function : PCM_DIN[0]
4
PIO18
Digital: Bidirectional with programmable
strength internal pull- up/pull-down
Programmable I/O line 18.
Alternative function : PCM_DOUT[0]
5
PIO17
Digital: Bidirectional with programmable
strength internal pull- up/pull-down
Programmable I/O line 17.
Alternative function : PCM_SYNC
6 PIO16
Digital: Bidirectional with programmable
strength internal pull- up/pull-down
Programmable I/O line 16.
Alternative function : PCM_CLK
7 PIO15
Digital: Bidirectional with programmable
strength internal pull- up/pull-down
Programmable I/O line 15.
Alternative function : MCLK_OUT
8 GND Power Ground
9 USB_DN Digital USB Full Speed device D- I/O.
10 USB_DP Digital USB Full Speed device D+ I/O.
11 VCHG Analog VCHG voltage input.
12 VCHG_SENSE Analog
Charger input sense pin after external mode
sense-resistor. High impedance.
Note : If using internal charger or no charger,
connect VCHG_SENSE direct to VCHG.
13 CHG_EXT Analog
External charger transistor current control. Connect
to base of external charger transistor as per
application schematic.
14 SYS_CTRL Digital input
Typically connected to an ON/OFF push button.
Boots device in response to a button press when
power is still present from battery and/or charger
but software has placed the device in the OFF or
DORMANT state. Additionally useable as a digital
input in normal operation. No pull.
Additional function: PIO[0] input only
15 VBAT Power Battery voltage input.
