THD+N
f
in
= 1 kHz
48 kHz
B/W = 20 Hz → 20 kHz
-1 dBFS
- -87.5 - dB
Digital gain Digital gain resolution = 1/32 -24.0 - 21.5 dB
Stereo separation (crosstalk) - 80 - - dB
Max capacitive load Per terminal to ground - - 100 pF
Class-AB DAC audio output
Parameter Conditions Mi Typ Max Uni
Input Sample Width - - - 24 Bit
Input Sample Rate, F
sample
- 8 - 192 kHz
Output Power 0 dBFS, 32 Ω load
-3 dBFS, 16 Ω load
- - 30 mW
Load - 1 32 30k Ω
SNR
f
in
= 1 kHz
48 kHz
F
sample
B/W = 20 Hz → 20 kHz
A-Weighted
0 dBFS
32 Ω load
- 98.3 - dBA
THD+N
f
in
= 1 kHz
48 kHz
B/W = 20 Hz → 20 kHz
-1 dBFS
32 Ω load
- -87.5 - dB
Digital gain Digital gain resolution = 1/32 -24.0 - 21.5 dB
Stereo separation (crosstalk) - 80 - - dB
Max capacitive load Per terminal to ground - - 100 pF
