Envoy Installation, Commissioning & Operating Manual
SECTION 6 – TECHNICAL DATA
• Mains input voltage ; 230Vac, 50-60 Hz (Harmonised) +10% to -15% compliant with BSEN54
Pt4 : 1997 for fire alarm power supplies.
• Nominal system voltage 24V dc.
• Power supply : Current limited 1amp suits SLA batteries only. Charging voltage 27.6 volts +/-
0.2V
• Temperature range: -5 to +40
o
C. Maximum relative humidity = 95%
GENERAL DATA & CURRENT CONSUMPTION FIGURES
BATTERY SIZES
The panels have space for the following batteries, based on standard sizes as supplied by the manufac-
turer.
Part No Description Qty
Conventional
Sndr ccts
Qty
TWIN
WIRE
Zone/Sndr
ccts
Total
Sndr
Load
(Amps)
Quiescent
Current
Panel
Only in
Alarm
FCPENV-1 Compact non
extendable
2 2 1 57mA 100mA
FCPENV-1EXT Extendable version 2 2 1 57mA 100mA
PCENV-1Z-5 One zone hy-spec
extension zone card
1 1 - 19mA 56mA
PCENV-3Z-5 Three zone budget
extension zone card
- - - 28mA 35mA
FCPENV-1EXT-L Extendable version,
large cabinet
2 2 1 57mA 100mA
Part No. Batteries
FCPENV-1
Cabinet Size: 277W x 200H x 97D mm
Weight: 3.36Kg (without batteries)
2 x 1.2Ah 12 Volt SLA
2 x 2.0Ah 12 Volt SLA
2 x 4.5Ah 12 Volt SLA
FCPENV-1EXT
Cabinet Size: 400W x 200H x 97D mm
Weight: 4.2Kg (without batteries)
2 x 1.2Ah 12 Volt SLA
2 x 2.0Ah 12 Volt SLA
2 x 3.0Ah 12 Volt SLA
2 x 4.5Ah 12 Volt SLA
2 x 7.0Ah 12 Volt SLA
FCPENV-1EXT-L
Cabinet Size: 400W x 300H x 97D
Weight: 4.9Kg (without batteries)
As Above
